TS-605Y Conference Room Wall-mounted Speaker

The Details Related Solution Related Cases Related Video Download



Feature:


* The housing is made of the integral molding of polystyrene material, light in weight and easy to install in various application scenes.

* The front panel adopts iron mesh decorative parts, which is neat and beautiful.

* The mounting bracket supports angle adjustment, convenient for various application scenes.

* Adopt a 5.25-inch mid-woofer unit and a 25mm silk film tweeter unit.

* 5-key fixed switch for constant pressure volume adjustment.

* Built-in high-quality linear audio power transformer.

* Widely used in various small and medium conference rooms, banquet halls, hotels, commercial buildings, schools, entertainment places, etc.


Specification:


Model

TS-605Y

Rated power

100W

Peak power

400W

Maximum SPL (rated/peak)

106dB/112dB

Rated impedance

Frequency response

80Hz-20kHz

Sensitivity

86dB+-3dB

Speaker

5.25-inch mid-woofer + 25mm silk film tweeter

Size

185x105x337mm (width×depth×height)

Weight

4.1kg
