T-4535C Ultra-thin speaker

The Details Related Solution Related Cases Related Video Download


Feature:


* Ultra-thin aluminum alloy structure, 32mm in thickness; sturdy, corrosion-resistant, and durable.

* Imported polymer multi-layer honeycomb diaphragm, low Young's modulus, light weight, high bending resistance and moderate damping.

* Built-in 4 drivers, NdFeB strong magnetic circuit; two 20mm silk diaphragm tweeters.

* 360 degrees of sound coverage, plane wave transmission, comfortable vocal sound, and long transmission distance.

* Wide frequency response range, 150Hz-18KHz plane sound.

* Ultra-thin (32mm) housing, high-strength aluminum alloy material, fine anodized grain surface, elegant appearance.

* Support multi-point installation, horizontal and vertical installation.

* Resistant to mildew, moisture and salt mist.

* Application: PA system in airports, cars, railways and subway stations; internal broadcasting in ships and warships; PA system and emergency broadcasting in schools, shopping malls, hotels, and institutions; emergency broadcasting in public places such as parks and squares.


Specification:


Model

T-4535C

Rated power

50W

Max SPL

104dB

Sensitivity

88dB ±3dB

Voltage

100V

Frequency response

80Hz -20KHz

Diaphragm area

Two 156mm×314mm

Driver

4 woofer drivers; 2 tweeter drivers.

Size

450×350×32mm

Weight

4.9Kg
