Description:
It works with the audio processor to form a set of high-end entertainment and conference professional sound system with outstanding vocal performance. It is suitable for various high-end conference rooms and multi-function halls as the main speaker or auxiliary speaker.
Feature:
* Adopt a mid-woofer and an annular polyethylene diaphragm compressed tweeter.
* 15mm birch housing, light weight, wear-resistant spray paint treatment, and dust-proof net cotton inside.
* The frequency divider in precise design is used to optimize the vocal MF performance.
* The entire series is equipped with efficient high-power amplifier modules and powerful DSP audio processor. Through different applications of the system, it supports comprehensive parameter settings, including 6 parameter equalization, frequency division, delay, and limit.
* Multiple screw hoisting holes, a pole socket with a diameter of 35mm, various installation methods.
Specification:
|
Model |
TS-610P |
TS-612P |
TS-615P |
|
Impedance |
8Ω |
8Ω |
8Ω |
|
Frequency response |
55Hz-20KHz |
50Hz-20KHz |
45Hz-20KHz |
|
Rated power |
300W |
350W |
450W |
|
Peak power |
1000W |
1400W |
1800W |
|
Sensitivity |
98dB/W/M |
99dB/W/M |
100dB/W/M |
|
Max SPL(rated/peak) |
123dB/128dB |
124dB/130dB |
127dB/133dB |
|
Coverage angle |
(H)80° (V)60° |
(H)80° (V)60° |
(H)80° (V)60° |
|
Tweeter |
1.4" compressed tweeter ×1 |
1.7" compressed tweeter ×1 |
1.73" compressed tweeter ×1 |
|
Woofer |
10" woofer ×1 |
12" woofer ×1 |
15" woofer ×1 |
|
Line input sensitivity |
0dB |
0dB |
0dB |
|
Size (H×W×D) |
510×325×300mm |
560×360×380mm |
660×435×430mm |
|
Weight |
18.5Kg |
21.8Kg |
28.8Kg |
|
Power supply |
AC 220V 50Hz |
AC 220V 50Hz |
AC 220V 50Hz |
|
Power consumption |
240W |
280W |
360W |
