Description:
It is suitable for the lighting of buildings, curtain walls, residential areas, commercial plazas, high-end office buildings, bridges, highways, etc.
Feature:
* Reasonable heat dissipation path design enables the heat of the LED to be quickly conducted through the luminaire structure to ensure the luminous efficiency and lifespan of the LED；
* Waterproof, dustproof and corrosion resistant；
* Uniform luminescence, high luminous brightness.
Specification:
|
Model |
TL-LH5302 |
TL-LH5303 |
TL-LH5304 |
|
Input voltage/power |
AC220V/50Hz/18W |
AC220V/50Hz/24W |
AC220V/50Hz/36W |
|
Light source |
EPISTAR/18PCS |
EPISTAR/24PCS |
EPISTAR/36PCS |
|
Beam angle |
30°(15°, 45°, 60° optional) |
||
|
Color temperature |
3000K (1900K, 2100K, 4000K, 5700K optional) |
||
|
Light effect |
≥80lm/W |
||
|
Color rendering index |
Ra≥80 |
||
|
Color tolerance |
SDCM≤5 |
||
|
Light source life |
50000H |
||
|
Control method |
ON/OFF |
||
|
IK Class |
IK08 |
||
|
IP Class |
IP65 |
||
|
Shell material |
Aluminum + Transparent PC |
||
|
Shell color |
Sand gray |
||
|
Installation method |
Screw fixed |
||
|
Product Size |
ø108*300mm |
ø108*300mm |
ø145*300mm |
Please leave a message if necessary, we will contact you as soon as possible!
