The interactive flat panel integrates application modules such as presentation, writing, interaction and sharing to create a simple paperless meeting/teaching scene, and to easily realize an efficient, convenient and harmonious meeting/teaching method.
* 4K UHD display, zero lamination design, AG tempered glass, high color gamut.
* Built-in Android operating system, support optional ultra-thin plug-in PC module.
* High degree of touch algorithm optimization, fast response, high writing and presentation fluency.
* Support operating signal source, volume and others by touch under the display status of signal sources.
* Support anti-light interference, use as usual under direct sunlight
* Support HDMI channel signal input smart wake-up function in standby mode.
* Support touch menu, including return key, menu operation, task preview, channel switching, volume adjustment, shortcut whiteboard, etc.
* Support any channel writing annotation function.
* Support channel memory function, enter the home page by default when booting, support custom named channel function.
* In standby mode, HDMI channel signal input intelligent wake-up.
* Support wireless screen transmission.
* Support WIFI 6.
* Support intelligent light sensing to adjust backlight.
* Support recording screen, electronic whiteboard and handwritten annotation, can meet various requirements of training classes.
Model
TV-98810
Processor
Mali-G52 MP2 dual-core, Quad-Core A55 quad-core
OS
Android 11
RAM
4GB
Storage
32GB
Screen type
LED LCD screen
Screen size
98 inches（16：9）
Screen display size
2160.5（H）×1217.3（V）mm
Physical resolution
3840（H）×2160（V）
Pixel pitch
0.5622×0.5622mm
Color gamutNTSC(Typ)
72%
Response time
Typ：6.5ms Max：12ms
Refresh rate
60Hz
Chromaticity
1.07G (10bit+FRC)
Brightness
450 cd/㎡
Contrast
1200:1
Viewing angle
178°(H/V)
Backlight lifespan
≥50000h
Audio channel
2.0
Speaker
2 x 15W@ 8Ω
Input port
TYPE-C*2；HDMI*1；TUOCH*1；USB3.0*2；HDMI2 IN*1；HDMI1 IN*1；RJ45 IN*1；AUDIOIN*1；VGAIN*1；DPIN*1；
Output port
OPTICAL OUT*1；USB2.0*1；TOUCH*1；USB3.0*2；WIFI*4；HDMI OUT*1；RJ45 OUT*1；LINE OUT*1
Communication port
RS232*1
Touch embedding mode
Built-in all-in-one, non-external design
Touch sensing technology
Infrared induction recognition touch technology; PC: 20 points / Android: 10 points
Writing method
Fingers, stylus or non-transparent objects larger than 5mm in diameter (multi-touch 8mm)
Writing height
3.5mm
Writing screen surface hardness
7H
Output coordinates
32767(W)*32767(D)
WiFi
802.11a/b/g/n/ac/ax+Bluetooth5.0，working frequency: 2.4GHz/5GHz, working distance: 12m
Power supply
100-240V~50/60Hz input
Standard power consumption
≤4000W
Standby power consumption
≤0.5W
Working temperatur
0℃～40℃
Working humidity
≤80%RH
Overall size（L*H*D）
2217.84mm*1326.29mm*94.8mm
Package size（L*H*D）
2401mm*1490mm*320mm
Weight
Net weight: 98±1kg，gross weight: 127.9±2kg
