TS-9120 Long-distance Driver

The Details Related Solution Related Cases Related Video Download

Description:

In the multimedia application system, a display is always needed to display high-definition picture quality in large distance within the scope of application. To solve this kind of problems in engineering and design of TS-9120 video signal pre emphasis driver, can achieve high bandwidth (400Mpixel band wide), high quality, the video signal transmission distance 120 meters long, to ensure that the signal is not affected by external interference in the transmission process, does not appear to decay; can improve the image signal distortion in the long distance transmission, double image, trailing.

Features:

* Support signal formats: RGBHV, RsGsBs, YPbPr/YCbCr.

* Support the video signal brightness and sharpness, the front segment adjustable pre emphasis.

* Support (pixel band wide) @-3dB 400M bandwidth. All outputs the perfect support for Full HD 1920x1200@60Hz or 1920x1080p@60Hz.

* Support for the ideal reduction maximum transmission distance is 120 meters (1024x768@60).

* HV input impedance select button, select 510R or 75R input matching.

Specifications:

Model	TS-9120
Video input
Interface	15-pin HD female interface
	1Vpp component video or Y and composite video in S-video;
Signal strength	0.7Vpp RGB (computer signal); 0.3Vpp component video
	Cb/Cr or Pb/Pr, C in S-video
Min/max level	Analog signal: 0.5V ~ 2.0Vpp
Impedance	75 Ω
Return loss	-30dB@5MHz
Genlock	0.3V-0.4Vpp
Maximum DC offset error	15mV
Long-line driver interface part video
Gain	Minimum 0.2dB (0~10MHz bandwidth)
	Maximum 1.8dB ((0 ~ 10MHz bandwidth)
	Minimum 0.4dB (10M ~ 400MHz bandwidth)
	Maximum>6dB (10 ~ 400MHz)
Differential phase error	<2.0 degrees, 3.58MHz (only when the compensation file below 40 meters)
Differential gain error	0.3%, 3.58-4.43MHz (only when the compensation file below 40 meters)
Maximum transmission delay	5nS(±1nS)
Signal type	RGBHV,RGBS,RGsB, RsGsBs,YPbPr/YCbCr,
Signal type	S-Video, composite video signal (CVBS)
Long-line drive part of the video output
Interface	BNC female interface
Min/max level	Analog signal: 0.5V ~ 2.0Vpp
Impedance	75 Ω
Return loss	-30dB@5MHz
DC compensation	Maximum ±5mV
Sync signal
Input/output type	RGBHV, RGBS, RGsB, RsGsBs
Input level	0.5V- 5.0Vpp,: 4.0Vpp normal
Output level	AGC-TTL: 5Vpp, unloaded (unterminated)
Input impedance	510 Ω / low impedance optional
Output impedance	75 Ω (monitoring output interface part);
	75 Ω (long-distant driver output interface part)
Polarity	Positive or negative (exactly consistent with the input)
Control type
Method	Manually select each file, subject to subjective feelings.
Specification
Input power	DC 9V 1.5A
Operating temperature	-20℃~ +70℃
Environment humidity	20%～80% relative humidity, no condensation
Installation	Hanging installation
Dimension (LxWxH)	163x152x32mm
