4-channel Professional Amplifier: TC-4500

The Details Related Solution Related Cases Related Video Download

4-channel Professional Amplifier :TC-4500


null

nullnullnull


Specification:


Model

TC-4500

Output power (1KHz/THD≤1%)



Stereo 8Ω: 4*500W; 4Ω: 4*800W; 2Ω: 4*1300W;

Bridge 16Ω: 2*1000W; 8Ω: 2*1600W; 4Ω: 2*2600W

Connector

XLR interface

Voltage gain (@1KHz)

36dB

Input sensitivity

2.2dBU(1V), 8.2dBU(2V)

Input impedance

10KΩ unbalanced, 20KΩ balanced

Frequency response (@1W power)

20-20KHz/±1dB

THD+N (@1/8 power)

≤0.01%

SNR (A-weighted)

≥102dB

Damping coefficient (@1KHz)

≥200@ 8 ohms

Separation (@1KHz)

≥85dB

Protection method

Over-voltage protection, under-voltage protection, over-current protection, DC protection, short circuit protection

Indicator light

Power, Fault, Clip, Signal

Cooling method

Fan cooling

Power supply

~ 220 50Hz

Overall power consumption

850W

Dimension (L×W×H)

484×353×44mm

Weight

7.8kg

Notes:

Output power: according to CEA-2006-B/CEA-490-A standard using 20ms pulse 1kHz sine wave measured under 1% total harmonic distortion.

Overall power consumption: according to GB4943.1-2022 test method: measured under 1kHz sine wave rated load 1/8 power conditions.
