Description：
It is a high-performance digital audio processor highly integrating multiple audio processing technologies, with 4 inputs and 8 outputs. It adopts DSP audio processing technology to provide users with excellent sound quality. It is mainly used in medium and large venues such as stadiums, auditoriums, banquet halls, exhibition halls, and multimedia conferences.
Feature:
* Each input channel: 4 balanced line inputs, standard XLR interface, balanced connection.
* Each output channel: 8 balanced line outputs, standard XLR interface, balanced connection.
* Provide 24bit/48KHz sound quality .
* Full-featured matrix mixing, flexible and simple signal routing operations, routing path and level size can be finished with one button.
* Support FIR filter
* Built-in digital audio processing algorithms: gain, delay, EQ, mixing matrix, compressor, distribution and limiter.
* Support automatic memory protection after power failure.
* Support channel gang control function.
* Support both USB and RJ45 connection methods for PC software control.
* Equipped with control software, intuitive and graphical interface; support XP/Windows7, 8, 10 and other systems.
Specification：
|
Model |
TS-P480 |
|
Input channel |
Pre-amplifier, delayer, extender, compressor, 31-band graphic equalizer |
|
Output channel |
15-band parametric equalizer, delayer, crossover, FIR filter, high and low pass filter, limiter |
|
Sampling rate |
48K |
|
Frequency response |
20Hz-20kHz ±0.5dB |
|
THD + noise |
＜0.002% @1kHz ,4dBu |
|
D/A dynamic range (A-weighted) |
120dB |
|
A/D dynamic range (A-weighted) |
120dB |
|
Input impedance (balanced) |
20KΩ |
|
Maximum output impedance (balanced) |
100Ω |
|
Channel separation |
1kHz, 100dB |
|
Input KCMR |
60Hz, 80dB |
|
Maximum output level |
+20dBu, balanced |
|
Maximum input level |
+20dBu, balanced |
|
Working temperature |
0℃-40℃ |
|
Power supply |
AC110V-220V, 50Hz/60Hz |
|
Power consumption |
<40W |
|
Size (width x depth x height) |
482×258×45(mm) |
|
Net weight |
2.56kg |
|
Gross weight |
3.56kg |
