T-601F Wall Mount Speaker

The Details Related Solution Related Cases Related Video Download


Feature:


* Indoor wall-mounted speaker with unique shape design, streamlined appearance, one-piece injection molding structure and metal mesh structure.

* 2 frequency division design,equipped with a 6-and-a-half-inch woofer and a 2-and-a-half-inch tweeter, the low frequencies are full and the trebles are clear.

* The built-in high-performance audio transformer can reduce the loss caused by impedance in the circuit.

* The mesh cover adopts the technology of sticking breathable cotton inside, which can prevent dust or liquid from entering and affect the sound quality, protect the speaker and increase the service life

* Simple hanging method facilitates installation.

* Suitable for schools, hotels, hotels, corridors, supermarkets, etc.


Specification:


Rated power (100V)

10W

Rated power (70V)

5W

Sensitivity

91dB ±3dB

Max SPL

101dB ±3dB

Impedance

Black: COM, Red: 1KΩ

Frequency response

130Hz-20kHz

Speaker unit

6.5"×12.5"×1

Dimension

276(H)×182(W)×103(D)mm

Weight

1.35kg
