Feature:
* Optics: 2 sets of optical lenses (3-layer coating) with high temperature resistance and strong light transmittance.
* Color wheel: 11 color gels + 1 white light, two-way rainbow effect, adjustable speed, flexible positioning function.
* Fixed gobo wheel: 14 fixed gobos + 1 white light, one-way flow, adjustable speed, flexible positioning function.
* Prism: Octagonal rotating prism + four-row lens, two-way rotation, superimposition, adjustable speed.
* Strobe: With synchronous, asynchronous, and random strobe modes, adjustable speed.
* Atomization: 1 independent atomization effect, the light spot is soft and natural.
* Scanning range: X-axis 630°/2.7 S, Y-axis 270°/1.5 S, accurate scanning positioning.
* Display interface: 2.4-inch LCD widescreen interface in Chinese and English; with a rechargeable battery, you can enter the menu to set the address code and perform other settings without powering it on; the menu is hierarchical and the graphical interface is user-friendly.
* Intelligent heat dissipation: Using wind direction drainage and intelligent temperature monitoring technology, built-in NTC temperature control function, when the LED is overheated, the output power of the LED will be intelligently reduced.
* Special function: Gyroscope: The gyroscope function is turned on, and the Y-axis is automatically compensated and calibrated. Autofocus: 3-25.5M autofocus.
Specification:
Model |
TL-SL172 |
Input voltage |
AC110V-240V 50/60Hz, 250W |
Light source |
Appotronics 200W LED Module |
Average lifespan |
50000H |
Color temperature |
10000K |
Beam angle |
2.0° |
Control mode |
DMX512 protocol, support RDM protocol and program online update function, support Art-net Ethernet data interface (DMX wireless function optional) |
Channel |
17 channels |
Fixture material |
High temperature resistant plastic + molded alloy material |
Protection class |
IP20 |
Fixture size (L×W×H) |
310×210×466mm |
Package size (L×W×H) |
385×365×490mm |
Gross weight |
15.1kg |
Net weight |
12.5kg |
