TL-SL172 Moving Head Beam Light

The Details Related Solution Related Cases Related Video Download

Feature:


*  Optics: 2 sets of optical lenses (3-layer coating) with high temperature resistance and strong light transmittance.

*  Color wheel: 11 color gels + 1 white light, two-way rainbow effect, adjustable speed, flexible positioning function.

*  Fixed gobo wheel: 14 fixed gobos + 1 white light, one-way flow, adjustable speed, flexible positioning function.

*  Prism: Octagonal rotating prism + four-row lens, two-way rotation, superimposition, adjustable speed.

*  Strobe: With synchronous, asynchronous, and random strobe modes, adjustable speed.

*  Atomization: 1 independent atomization effect, the light spot is soft and natural.

*  Scanning range: X-axis 630°/2.7 S, Y-axis 270°/1.5 S, accurate scanning positioning.

*  Display interface: 2.4-inch LCD widescreen interface in Chinese and English; with a rechargeable battery, you can enter the menu to set the address code and perform other settings without powering it on; the menu is hierarchical and the graphical interface is user-friendly.

*  Intelligent heat dissipation: Using wind direction drainage and intelligent temperature monitoring technology, built-in NTC temperature control function, when the LED is overheated, the output power of the LED will be intelligently reduced.

*  Special function: Gyroscope: The gyroscope function is turned on, and the Y-axis is automatically compensated and calibrated. Autofocus: 3-25.5M autofocus.


Specification:


Model

TL-SL172

Input voltage

AC110V-240V 50/60Hz, 250W

Light source

Appotronics 200W LED Module

Average lifespan

50000H

Color temperature

10000K

Beam angle

2.0°

Control mode

DMX512 protocol, support RDM protocol and program online update function, support Art-net Ethernet data interface (DMX wireless function optional)

Channel

17 channels

Fixture material

High temperature resistant plastic + molded alloy material

Protection class

IP20

Fixture size (L×W×H)

310×210×466mm

Package size (L×W×H)

385×365×490mm

Gross weight

15.1kg

Net weight

12.5kg
