TK-S180 Linear Array Speaker

The Details Related Solution Related Cases Related Video Download



Description:


The passive linear array subwoofer consists of a 18" woofer. It adopts the compressed acoustic design to enable farther sound transmission. It is required to work with the full-range linear array speakers. And it is suitable for various small and medium performances, theaters, auditoriums, banquet halls, multi-function halls and other high-end venues.


Feature:


* An 18" woofer with high efficiency and high sensitivity.

* High-quality high-density birch wood housing, precision CNC processing.

* Professional speaker sockets and plugs with good electrical characteristics.

* Emery spraying process, high-end and wear-proof surface.


Specification:


Model

TK-S180

Type

Linear array subwoofer

Nominal impedance

Frequency range

35Hz-250Hz

Rated power

800W

Peak power

3200W

Sensitivity

102dB/W/m

Maximum SPL(rated/peak)

131dB/137dB

Woofer

18"×1

Net weight

49.7kg

Size

575×924×700mm(H×W×D)
