Specification:
Model |
VA-565 |
VA-575 |
VA-585 |
Power Taps @100V |
6W, 3W, 1.5W, 0.75W, 0.38W |
6W, 3W, 1.5W, 0.75W, 0.38W |
15W, 7.5W, 3.75W, 1.87W, 0.93W |
Power Taps @70V |
3W, 1.5W, 0.75W, 0.38W, 0.19W |
3W, 1.5W, 0.75W, 0.38W, 0.19W |
7.5W, 3.75W, 1.87W, 0.93W, 0.46W |
Impedance |
Com/1240Ω/1840Ω/3340Ω/6790Ω/13300Ω |
Com/1390Ω/1980Ω/3410Ω/7080Ω/13230Ω |
Com/670Ω/1300Ω/2600Ω/5300Ω/8950Ω |
SPL |
92dB |
92dB |
93dB |
Frequency Response (-10dB) |
130-18KHz |
120-18KHz |
80-20KHz |
Finish |
Baffle: Steel, White |
Baffle: Steel, White |
Baffle: Steel, White |
|
Grille: Steel, White Cover: Steel, Red |
Grille: Steel, White Cover: Steel, Red |
Grille: Steel, White Cover: Steel, Red |
Speaker Driver |
5" x 1 |
6" x 1 |
8" x 1 1.5" x 1 |
Cutout Size |
157mm |
207mm |
240mm |
Dimension |
180 x 147mm |
230 x 148mm |
270 x 152mm |
Weight |
1.2Kg |
1.6Kg |
1.7Kg |
